Using it

Reachable — the console: six answer cards and a printed report

The console reads two things: the committed incident reports (worker/out/*.json, rendered statically, always available) and the live worker API (:8787, which talks to HydraDB). Pages that need the worker degrade on purpose when it is down — they say so, they never guess. This chapter walks the console in the order you would use it; the grammar, ports and caps live in the reference chapters.

Add a repository

Live: Services.

On Services, type owner/repo or paste a GitHub URL and press Add. The job runs in the worker and its progress streams into the job card, four steps in order:

lockfiles — read the commit history of the lockfile at the repository root and walk every snapshot; each becomes a Lockfile node whose RESOLVED edges are the flattened install tree the package manager wrote.
packages — enrich every resolved version from the registry: publish times, removals, maintainers, weekly downloads.
advisories — link OSV advisories to the ingested versions, with the installable window on the AFFECTS edge.
reach — scan first-party JS/TS at the newest exposed lockfile commit for imports of the advisory-affected packages, so verdicts can say L0 or L1 rather than unscanned.

Supported lockfiles: npm package-lock.json (lockfileVersion 2 and 3) and pnpm pnpm-lock.yaml (6.x and 9.x), at the repository root; package-lock.json is tried first and the first path with commits wins. yarn.lock and bun lockfiles are detected and refused with a clear "not supported yet"; monorepo sub-directories are not scanned yet. Steps show — (not a time) while running and live i/n progress; a job cut off by a worker restart comes back as interrupted with a retry button (retries are idempotent), and the table flags a service whose latest job did not finish as partial · retry. When the job completes, view on board opens the service where it now sits. The graph the guide describes holds 13 services and 246 lockfile snapshots.

Read a report

Live: the report.

Open Incidents and click an advisory. The report for MAL-2025-46974 reads top to bottom; the right rail is a mini-map that tracks the section in view.

Headline — one sentence and a six-stat strip: 3 services exposed · 3 resolved while live · 0 act now · 0 imported · 3 present only · 0 unscanned.
Blast radius — the graph version → dependency → lockfile → service, amber where the lockfile resolved while the version was installable.
Q1 exposed — verdict distribution and the service table: 6 lockfiles, 7.06 ms warm.
Q2 versions — publish times, the removed flag and the window; the upper bound chip sits next to live_to because npm publishes no takedown time.
Q3 while live — the installable-window timeline and the evidence table (in window · pins removed), 4.81 ms.
Q4 maintainers — co-maintained packages ranked by weekly downloads with the services resolving each today; exposure is computed for the eight most downloaded, the rest read — not computed. This is the slow card: 13.60 s on the guide incident.
Q5 look-alikes — near-names by kind and edit distance, 2.60 ms.
Q6 ledger — the verdict per service, the command that regenerates the report and the README badge; then Beyond the watched set and provenance.

Every card has a hydradb strip with the statement, the row count and the wall-clock ms; it can be collapsed but never hidden. Click a service in Q1 or the ledger for the service detail: one card per exposed lockfile with the proving path as a chain (debug@4.4.2 ←DEPENDS_ON← agent-base@6.0.2 ←RESOLVED← lockfile), commit sha and time, and the reachability note (files scanned, imports found).

Live: the print view · Markdown · Slack text · JSON.

Export PDF in the report header prints the report as a paper document: a light print palette (the same tokens, redefined for paper), an A4 flow with a title block (advisory, kind, severity, worst verdict, published, generated, engine digest), every "How HydraDB answered this" statement open as a light code block, every capped table fully expanded, the stat strip on one row, the blast graph and timeline scaled to the page width, and a provenance line at the end. The sidebar, rail, buttons and "Beyond the watched set" are left out. Save as PDF from the dialog — the file name is proposed as reachable-<advisory>-report.pdf. Opening a report with ?print=1 puts it in the same expanded state on load, so a link can be shared or printed with Ctrl/Cmd+P.

Share opens a small menu next to it:

action	what you get
Copy for Slack	mrkdwn — bold headings, bullets, code spans, the six headline numbers, Q1–Q6 in short lists (`… +N more` when capped), the link
Copy for Discord	Markdown subset under Discord's 2 000-character limit — the same story, lists truncated honestly
Copy Markdown / Download .md	GitHub-flavoured Markdown: tables for every question, each executed statement in a collapsible block, provenance
Download .json	the committed report itself (`worker/out/<advisory>.json`)
Copy link · Copy print link	the report URL, or the `?print=1` variant

The same formats are served at /incident/<advisory>/export?format=md|slack|discord|txt|json (add &download=1 for an attachment). Every number and statement in every format is read from the same JSON the page renders; nothing is re-typed. Pasting a report link into Slack, Discord or X unfurls a card for that incident (advisory, summary, the six numbers, the worst verdict).

Ask

Live: Ask.

Type a question on Ask, or click one of the suggested shapes. There is no language model: the question is matched against a small grammar, each shape maps to one verified statement, and the answer is one sentence, then the rows, then the statement that produced them. Identifiers are recognised by shape — advisory ids (MAL-, GHSA-, CVE-), owner/repo, package@version, bare package names including @scope/name. If a question does not parse, the page tells you the shapes it knows; an empty result renders a grey none chip with an honest sentence. The full grammar is in Ask grammar.

Board

Live: Board.

Five lanes — Act now · Resolved while live · Imported · Unscanned · Present only. Lanes are computed from the data, not assigned: a card moves only when the graph changes. The compact toggle drops the detail lines.

Beyond the watched set

Live: the section at the end of the report.

At the bottom of every report, a GitHub code search for public repositories whose lockfile pins an affected version today, with a watch button per row. These are candidates, not verdicts: watching one runs the four steps above, and only then does the service get a verdict.

Coding agents

Twelve tools over MCP. The quickest route needs nothing installed: generate a key and add the deployed worker as an HTTP MCP server — claude mcp add --transport http reachable <url>/mcp --header "Authorization: Bearer …", or the same URL and header in any client that speaks MCP (see Running it). If you have the repo, the stdio server works against your own worker with no key at all. Every tool that answers a question about the graph carries the Cypher that produced it under cypher and its caveats under limitations; list_services and the two job tools return registry and job state, so they carry neither. Only watch_repository writes, and a read-only key is refused on it.

tool	what it answers
`exposed_services`	which watched services resolved an affected version (Q1), optionally narrowed to one service
`resolved_while_live`	which services committed a lockfile pinning the bad version while it was installable (Q3)
`affected_versions`	the versions an advisory affects, first affected, removal and the window (Q2)
`maintainer_fanout`	maintainers of the affected packages and the other packages they publish, with resolving services (Q4)
`typosquats`	package names within one edit of a package (Q5); distance and kind are facts, "typosquat" is a hypothesis
`why_pulled_in`	the dependency chain(s) through which a service resolves a package, per lockfile
`who_depends_on`	which watched services pin an exact package version
`list_services`	the watched repositories with lockfile count and latest commit
`watch_repository`	start watching a repository; returns a job id
`job_status`	progress and log of an ingest job
`find_public_victims`	public repositories whose lockfile pins an affected version today — candidates, not verdicts
`cypher`	a read-only OpenCypher statement (`MATCH`/`CALL`/`RETURN` only; writes are refused)

Badge

Live: a badge.

/badge/{owner}/{repo}.svg — a two-cell SVG for READMEs: reachable · L2 of N in the verdict colour; unscanned in grey; no exposure recorded in neutral when the service is in no composed incident (never green — absence of a record is not a clean bill). The Services table and the Q6 ledger show the markdown to paste.

Read-only deploys and degraded states

The console can be deployed with only the committed reports: the incident pages, board and badge work; Services, Ask and Graph show their degraded states instead of stale numbers. Nothing is served from a cache that pretends to be live. When the worker is up but a request fails, the error surfaces as a toast; unknown routes get a designed 404. Everything is reachable by keyboard, focus rings are always visible, hit areas are at least 40 px, prefers-reduced-motion turns every animation off and shows every number at its final value. The console is dark only.

The pages, in one line each

Incidents /incidents — every composed advisory, sorted by act-now count; click a row for the report.
Report /incident/{advisory} — the six questions with the executed statement on every card.
Service detail /incident/{advisory}/{owner}/{repo} — one card per exposed lockfile with its proving path.
Board /board — five lanes computed from the data.
Services /services — the watched registry, add-by-URL ingest jobs, badges.
Ask /ask — typed questions to verified statements.
Graph /graph — live counts per label, the frozen schema, ingest jobs and a force-directed neighbourhood explorer (wheel zooms, drag pans, click opens a node panel with "ask about this").
Docs /docs — this guide, rendered from the repo's own markdown.
