Graph schema

Every construct here was verified against a running HydraDB node before freezing (see AGENTS.md §8). Change it only with a probe result in hand — a schema change after ingest means a full reload.

Ids: integers, never purls

HydraDB node and relationship ids must be non-negative integers. So:

• id — the vertex/edge id, a deterministic 52-bit hash of the human key. It is not a readable property on nodes; use key.
• key — the human key string, stored as a property on every node. Selector lookups (algo.MSpaths sourceProperty) run against key.
• eid — on every relationship, a mirror of its id, because r.id is unusable in WHERE/RETURN (engine parses it as a node-id expression).

gid(key) = int.from_bytes(blake2b(key, digest_size=8), "big") >> 12   # 52 bits
eid(src_key, rel_type, dst_key) = gid(f"{src_key}|{rel_type}|{dst_key}")

52 bits, not 63: the engine accepts the full signed-64 range, but the web console is JavaScript and JSON numbers above 2^53 lose precision silently. Python's builtin hash() is disqualified — PYTHONHASHSEED randomises it per process, so every re-ingest would create duplicates instead of MERGE-ing. Collision odds by birthday bound: ~1e-6 at 100k nodes. load.py keeps a gid → key map and raises on a mismatched collision.

Key formats (purl-shaped, unchanged from the spec)

pkg:npm/express                       Package
pkg:npm/express@4.18.2                Version
npm:sindresorhus                      Maintainer
GHSA-g7cv-rxg3-hmpx  ·  MAL-2026-3460 Advisory
svc:twbs/bootstrap                    Service
lock:twbs/bootstrap@a3f9c21           Lockfile
file:twbs/bootstrap:js/src/dom.js     File
sym:npm/qs@6.11.0#parse               Symbol

Nodes

Every node has id (int, gid(key)) and key (string). Timestamps are int epoch seconds, UTC — the engine has no date functions, and comparing a string against an int errors the whole query.

Label	Properties
Package	name, ecosystem ('npm'), downloads int (weekly; only on packages the packages stage enriched)
Version	version, published_at int, removed bool, malicious bool (only written true, by the advisories stage)
Maintainer	login, email_domain; account_created int and twofa bool exist in the fixture only — the public registry does not expose them, real ingest never writes them (null rows are dropped, never stored)
Advisory	kind ('malware' | 'cve'), severity, severity_rank int, published_at int, summary
Service	name, repo_url, criticality int
Lockfile	committed_at int, sha, path
File	path, language ('javascript' | 'typescript', by extension)
Symbol	name — fixture only; L2 was cut, no ingest stage writes Symbol nodes

Version.removed = the version key is present in the registry time map but absent from versions — npm keeps the publish timestamp after erasing the artifact. It proves a removal, not why; malicious is set only when an advisory says so.

Advisory.severity_rank exists because you cannot ORDER BY a CASE, and MAL records carry no CVSS. critical=4 high=3 medium=2 low=1 unknown=0.

Relationships

Every relationship has id and eid (both eid(src, type, dst)).

Type	Shape	Properties	Source
VERSION_OF	(Version)→(Package)	—	registry
DEPENDS_ON	(Version)→(Version)	range	lockfile (packages[*].dependencies + resolved path)
MAINTAINS	(Maintainer)→(Package)	—	registry
AFFECTS	(Advisory)→(Version)	live_from int, live_to int, live_to_kind	OSV + registry
HAS_LOCKFILE	(Service)→(Lockfile)	—	GitHub
RESOLVED	(Lockfile)→(Version)	at int (= lockfile committed_at)	lockfile
CONTAINS	(Service)→(File)	—	sources/reach.py — regex import scan of first-party JS/TS at the exposed commit (L0/L1)
IMPORTS	(File)→(Package)	line int	sources/reach.py
USES_SYMBOL	(File)→(Symbol)	line int	fixture only (L2 cut)
VULNERABLE_SYMBOL	(Advisory)→(Symbol)	inferred bool (always true)	fixture only (L2 cut)
NAME_SIMILAR_TO	(Package)→(Package)	distance int (1 or 2), kind (scope | hyphen | homoglyph | prefix_suffix | insertion | deletion | transposition | substitution | edit2)	typosquat.py, materialised at ingest (suspect → popular)

The temporal window — what "while it was live" means

The window lives on the AFFECTS edge, not on Version: a version hit by two advisories has two windows, and only an edge can carry that. Q3 is then one engine-side predicate: RESOLVED.at BETWEEN AFFECTS.live_from AND live_to.

Field	Value	Honesty
live_from	registry time[version]	exact — npm keeps it after takedown
live_to	min(next_surviving_version_publish, advisory_published) for malware (only bounds >= live_from count); the sentinel 4102444800 (2100-01-01) = still live, used for every CVE and for malware with no bound	upper bound — npm publishes no takedown time anywhere
live_to_kind	'upper_bound' when a bound was found; 'unbounded' with the sentinel (CVEs, or malware with no bound); 'exact' reserved for a real takedown timestamp — npm never gives one, so it is never written today	rendered next to every window in the UI

Version.published_at and AFFECTS.live_from are the same number by construction; the duplication is deliberate so Q3 never needs a second hop.

Q3 is only offered for Advisory.kind = 'malware'. For an ordinary CVE the artifact stays on the registry indefinitely, live_to is unbounded, and "resolved while live" collapses into "resolved at all".

Two decisions, defended

Lockfile is a node. A service's exposure is a fact as of a commit. Each snapshot of package-lock.json is a Lockfile with committed_at, and its RESOLVED edges are the flattened transitive tree npm actually installed — so the closure for Q3 is already materialised per snapshot, and the question becomes a join plus a window predicate. algo.MSpaths is for Q1, where the deliverable is the path, not membership.

NAME_SIMILAR_TO is materialised at ingest so typosquat proximity is a traversal, not a scan.

Ingest rules the engine forces

• All writes are UNWIND $rows AS row …, ≤ 1000 rows per statement (hard cap 1024).
• MERGE (n {id: row.id}) SET n:Label, n.key = row.key, … — the MERGE pattern matches on id only, the label is applied in SET, every value from the row.
• Edge writes: MATCH (a:LabelA {id: row.src}), (b:LabelB {id: row.dst}) MERGE (a)-[r:TYPE {id: row.rid}]->(b) SET r.eid = row.rid, … — exactly one label per endpoint.
• No CREATE INDEX — graph-indexer indexes properties on write.
• Every timestamp coerced to int at the source boundary; ingest asserts non-null coverage on published_at, live_from, live_to, at before declaring done.
• Package names and versions pass ids.safe_purl() (strict allowlist, reject never escape) before they can reach an inline sourceValues literal.
